2.3 Multiple inputs into a single process

Learning objectives

Configure a Nextflow process to accept input from multiple channels.
Understand the importance of creating channels from process outputs to enable modular, reusable workflows.
Link multiple Nextflow processes using channels to form a chained workflow.

In this lesson we will transform the bash script 02_quant.sh into a process called QUANTIFICATION. This step focuses on the next phase of RNAseq data processing: quantifying the expression of transcripts relative to the reference transcriptome.

To do this, we will need to run Salmon's quant mode over the paired-end reads and the transcriptome index.

Open the bash script 02_quant.sh.

02_quant.sh

SAMPLE_ID=gut
READS_1="data/ggal/${SAMPLE_ID}_1.fq"
READS_2="data/ggal/${SAMPLE_ID}_2.fq"

salmon quant \
    --libType=U \
    -i results/salmon_index \
    -1 ${READS_1} \
    -2 ${READS_2} \
    -o results/${SAMPLE_ID}

Same as the previous lesson, this script contains the ${SAMPLE_ID} variable definitions which is used to connect sample names to FASTQ file paths. Within the salmon quant execution command:

--libType=U is a required argument for Salmon.
-i results/salmon_index is the directory output by the INDEX process.
-1 and -2 are flags for the respective paired reads (.fq).
-o outputs files into a directory called results/gut

2.3.1 Building the `QUANTIFICATION` process

Defining the process directives

Here is the empty process template with the container and publishDir directives we'll be using to get you started. Add this to your main.nf after where you defined the FASTQC process.

main.nf

process QUANTIFICATION {
  container "quay.io/biocontainers/salmon:1.10.1--h7e5ed60_0"
  publishDir "results", mode: 'copy'

  input:
    < process inputs >

  output:
    < process outputs >

  script:
  """
    < script to be executed >
  """
}

It contains:

Prefilled process directives container and publishDir.
The empty input: block for us to define the input data for the process.
The empty output: block for us to define the output data for the process.
The empty script: block for us to define the script for the process.

Defining the process `script`

Update the script definition with the Salmon command from the bash script. Again, we want to remove the definition of the Bash variables and just keep the salmon command:

main.nf

process QUANTIFICATION {
  container "quay.io/biocontainers/salmon:1.10.1--h7e5ed60_0"
  publishDir "results", mode: 'copy'

  input:
    < process inputs >

  output:
    < process outputs >

  script:
  """
  salmon quant --libType=U -i $salmon_index -1 $reads_1 -2 $reads_2 -o $sample_id
  """
}

The --libType=U is a required argument and can be left as is for the script definition. It can stay the same as in the bash script. The following need to be adjusted for the QUANTIFICATION process:

-i $salmon_index uses the Nextflow variable salmon_index to refer to the output directory from the INDEX process.
-1 $reads_1 and -2 $reads_2 use two more variables to refer to the FASTQ files from the previously defined reads_ch channel.
-o $sample_id outputs files into a directory named after the $sample_id.

Defining the process `output`

Salmon creates an output directory with whatever name is passed to the -o flag. In our case, we supplied -o $sample_id to Salmon, so our output will be a directory named after whatever is in the variable sample_id. For our test sample, the directory will be called gut/. Replace < process outputs > with the following:

main.nf

process QUANTIFICATION {
  container "quay.io/biocontainers/salmon:1.10.1--h7e5ed60_0"
  publishDir "results", mode: 'copy'

  input:
    < process inputs >

  output:
  path "$sample_id"

  script:
  """
  salmon quant --libType=U -i $salmon_index -1 $reads_1 -2 $reads_2 -o $sample_id
  """
}

Now our process will expect to find an output path with the same name as the sample_id variable.

Defining the process `input`

In this step we will define the process inputs. Based on the bash script, we have four inputs:

$salmon_index
$sample_id
$reads_1
$reads_2

These should look familiar!

The $salmon_index was output by the INDEX process, and $sample_id, $reads_1, $reads_2 are output by our reads_in. We will see how to chain these when we work on the workflow scope below.

For this process, we will be defining two inputs. Nextflow allows processes to be defined with any number of inputs.

First, add the input definition for $salmon_index. Recall that we use the path qualifier as it is a directory:

main.nf

process QUANTIFICATION {
  container "quay.io/biocontainers/salmon:1.10.1--h7e5ed60_0"
  publishDir "results", mode: 'copy'

  input:
  path salmon_index

  output:
  path "$sample_id"

  script:
  """
  salmon quant --libType=U -i $salmon_index -1 $reads_1 -2 $reads_2 -o $sample_id
  """
}

Secondly, add the tuple input:

main.nf

process QUANTIFICATION {
  container "quay.io/biocontainers/salmon:1.10.1--h7e5ed60_0"
  publishDir "results", mode: 'copy'

  input:
  path salmon_index
  tuple val(sample_id), path(reads_1), path(reads_2)

  output:
  path "$sample_id"

  script:
  """
  salmon quant --libType=U -i $salmon_index -1 $reads_1 -2 $reads_2 -o $sample_id
  """
}

You have just defined a process with multiple inputs!

How's it going?

Once you have defined the process block, select the "Yes" react on Zoom.

Calling the process in the `workflow` scope

Recall that the inputs for the QUANTIFICATION process are emitted by the reads_in channel and the output of the INDEX process. The reads_in channel is ready to be called by the QUANTIFICATION process. Similarly, we need to prepare a channel for the index files output by the INDEX process.

Add the following channel to your main.nf file, after the FASTQC process:

main.nf

// Define the workflow
workflow {

    // Run the index step with the transcriptome parameter
    INDEX(params.transcriptome_file)

    // Define the fastqc input channel
    reads_in = Channel.fromPath(params.reads)
        .splitCsv(header: true)
        .map { row -> [row.sample, file(row.fastq_1), file(row.fastq_2)] }

    // Run the fastqc step with the reads_in channel
    FASTQC(reads_in)

    // Define the quantification channel for the index files
    transcriptome_index_in = INDEX.out[0]

}

The syntax INDEX.out[0] specifies that we want to access the first output of the INDEX process. Numbering starts at zero, so [0] refers to the first output, [1] to the second, and so forth.

Advanced content: Different ways of accessing process outputs

Nextflow allows us to access the output of a process using the .out attribute. If a process has a single output, you can simply use <PROCESS_NAME>.out. If a process has 2 or more output channels, you need to use an integer index to access the corresponding outputs. An index is simply a number - starting at 0 - that indicates the place of an item within a list or array. We use square brackets to access values using an index - e.g. [0], [1], etc. Process outputs are ordered within the .out attribute based on the order in which they were defined. For example: .out[0] will access the first defined output, .out[1] will access the second output, and so forth.

For the sake of consistency, we have used the indexed method here (i.e. INDEX.out[0]), although we could have omitted the index and simply used INDEX.out since our INDEX process only has the single output.

Alternatively, the process output definition allows the use of the emit statement to define a named identifier that can be used to reference the channel in the external scope:

process

...
output:
path "salmon_index", emit: index
...

workflow

...
transcriptome_index_in = INDEX.out.index
...

Call the QUANTIFICATION process in the workflow scope and add the inputs by adding the following line to your main.nf file after your transcriptome_index_in channel definition:

main.nf

// Define the workflow
workflow {

    // Run the index step with the transcriptome parameter
    INDEX(params.transcriptome_file)

    // Define the fastqc input channel
    reads_in = Channel.fromPath(params.reads)
        .splitCsv(header: true)
        .map { row -> [row.sample, file(row.fastq_1), file(row.fastq_2)] }

    // Run the fastqc step with the reads_in channel
    FASTQC(reads_in)

    // Define the quantification channel for the index files
    transcriptome_index_in = INDEX.out[0]

    // Run the quantification step with the index and reads_in channels
    QUANTIFICATION(transcriptome_index_in, reads_in)

}

By doing this, we have passed two arguments to the QUANTIFICATION process as there are two inputs in the process definition.

Matching process inputs

Recall that the number of inputs in the process input block and the workflow must match!

If you have multiple inputs they need to be listed across multiple lines in the process input block and listed inside the parentheses and separated by commas in the workflow block.

Run the workflow:

nextflow run main.nf -resume

Your output should look like:

Output

Launching `main.nf` [shrivelled_cuvier] DSL2 - revision: 4781bf6c41

executor >  local (1)
[de/fef8c4] INDEX              | 1 of 1, cached: 1 ✔
[bb/32a3aa] FASTQC (1)         | 1 of 1, cached: 1 ✔
[a9/000f36] QUANTIFICATION (1) | 1 of 1 ✔

A new QUANTIFICATION task has been successfully run and have a results/gut folder, with an assortment of files and directories.

Summary

In this lesson you have learned:

How to define a process with multiple input channels
How to access a process output with .out
How to create a channel from a process output
How to chain Nextflow processes with channels
